Aquafine CSL Series

The CSL series is a compact, totally enclosed unit, which incorporates a UV treatment chamber with an electrical cabinet base containing all electrical components and instrumentation.These one-piece UV models are engineered for indoor installations and controlled operating environments. The CSL series is used in laboratory, hospital and hotel installations, as well as cosmetic, pharmaceutical and semiconductor manufacturing processes. Stainless baffles are d in the treatment chamber to induce turbulence and prevent channeling, maximizing the exposure toultraviolet radiation.

Product Description

·         Disinfection Model: CSL-8R

·         Fresh Water Flow Range (GPM): 80

·         RO/DI Flow Range (GPM): 100

·         Pipe Size: 3" Flange

·         Dimensions L x H X W: 41" x 20-3/4" x 11-1/2"

·         Weight (lbs): 238

·         Total Amps.: 4.2

·         Total Watts: .516 KW

Standard Features:

·         99% Plus Bacterial Reduction

·         Operating Pressure - 120 psig

·         Chamber - 316 Stainless Steel

·         Chamber - Passivated and Electropolished

·         Integral Ballast Enclosure: 304 Stainless Steel

·         LED UV Lamp Operating Display Panel

·         Running Time Meter: 99,999 Hours. - Non resettable

·         Socket Lok™

Optional Features

S-254 UV Optical Sensor

T-120 Temperature Safety Control

High Water Temperature Models

High Pressure Models (to 150 PSIG)

Sanitary Fittings

Lamp Out Alert

UV Aquafine CSL-8R

Optional Monitoring Package (See Details Below)

Optional Monitoring Package Details:

An integrated NIST traceable (optional) UV and temperature monitoring systemwill accurately monitor UV intensity and process water temperature of yourexisting UV treatment equipment from Aquafine. The new design improvesreliability and performance accuracy in one state-of-the-art monitoring technologysystem. Component cost savings and improved liability protection will be some ofthe key benefits you will have with this state-of-the-art monitoring system. Thedetector employs a Gallium Nitride (GaN) photodiode and a semiconductortemperature sensor in a single package, along with its on-board electronics forremote and local operation features:

Detector: UV and temperature sensors in a single housing

Optional NIST-traceable UV sensor calibration with certificate upon request

No optical filters, no degradation

Withstands non-operating temperatures of 250°F

121°C for steam sterilization at a maximum pressure of 250psi (17.2 bar)

Complete on-board electronics for UV and temperature

Absolute and percent UV readout options

Detector Cable: Water-resistant axial connector and cabling

No diffuser, therefore no UV solarization

Temperature sensor and controller does not calibration

Detector can be used for UV Monitoring Station and Aqualogic 2000™ system.
