PFI SWC1-10CA String Wound Cotton Filter Cartridge

Kami adalah importir distributor agen dan supplier terlengkap untuk menyediakan berbagai kebutuhan spare part filter untuk keperluan industri dengan price harga terbaik

PFI SWC1-10CA

·         Product Type : Filter Cartridge

·         Brand Name / Model : PFI SWC1-10CA

·         Construction : String Wound Filter

·         Media : Cotton

·         Filter Rating : 1 Micron

·         Dimensions : 10" Long

·         End Cap Configuration : Doe

·         Core Material : SS304

·         Flow Rate : 5 gpm (19 Lpm) per 10”

PFI cartridges are available with Polypropylene, or Cotton materials wound onto Polypropylene, 304 stainless steel or tinned steel cores. The cartridges can be used (in one combination of materials or another) in most areas chemical compatibility is of concern. Special materials are available for high temperature or unusually aggressive applications. Food grade product (FDA PP Fibre) is always available ex-stock. Activated carbon cartridges are available to remove unpleasant tastes and odors.

PFI FILTER CORE SELECTION GUIDE

Polypropylene:  economical core of choice for most applications in water and corrosives to 200ºF.

Tin Plated Steel: General purpose metal core for oils, solvents,paints, and other non-FDA applications. For use to 400ºF.

304 Stainless Steel: For high temperature applications on diluted acids and moderately corrosive fluids. For use to 750ºF.

316 Stainless Steel: For high temperature applications on strong acids and highly corrosive fluids. For use to 750ºF.

Glass-filled nylon for strong acids and highly corrosive fluids when polypropylene is not compatible.

PFI SWC1-10CA String Wound Cotton Filter Cartridge

PFI-PP Standard Polypropylene String Wound

For concentrated acids and alkalies, strong oxidizing agents, and corrosive fluids and gases. Easily incinerated to trace ash. For use to 200º F

PFI-PD FDA Grade Polypropylene String Wound

Ideally suited for potable water, Pharmaceutical and Food Processing Applications.

PFI-NC Natural Cotton String Wound

For oils, water, paints, organic solvents, alcohols, and petroleum. Non-FDA applications. For use to 300º F.

PFI-BC Bleached Cotton String Wound

Bleached to meet FDA standards for distilled water, beverages, vegetable oils, petroleum, fatty acids, and alcohols. For use to 300º F. FDA approved.

PFI-FG Fiberglass String Wound

Available in both standard and baked media. Baking removes all traces of oil sizing, yielding virgin glass fiber. For use to 750º F.
