HydroCompos PF-10-20-EHE Pleated Filter Cartridge Indonesia
Kami adalah importir distributor agen dan supplier terlengkap untuk menyediakan berbagai kebutuhan spare part filter untuk keperluan industri dengan price harga terbaik
BENEFITS
Exceptional dirt holding capacity and consistent particle retention. Constructed with gradient density, thermally bonded polypropylene microber media, PF-series have super high dirt holding capacity and consistent particle retention. PF-series have long life time and are d LESS changed out and LESS down time – SAVE cost and SAVE labour.
Widely used in a broad range of applications. With pure polypropylene constructions, PF-series are superior chemical compatibility and extensively used in a broad range of applications - filtrations of bulk chemicals, liquid polymers, coatings and etc.
An economical solution for your filtration alternative. With competitive prices of the PF series, they are an alternative to high cost membrane filters. PF-series are widely used to protect expensive final filters in serial filtration.
FEATURES
PF -series (Pleated Filter) are constructed with all polypropylene materials. Purely polypropylene constructions, PF -series do not contain any adhesives or additives and are highly recommended into the high purity applications. Gradient density, thermally bonded polypropylene media has an super high dirt holding capacities and provides the reliable retention characteristics.
APPLICATIONS
· Bulk chemicals, liquid polymers, coatings and inks filtration.
· Pre-filtration to protect expensive final filters.
· Post carbon bed and de-ionized bed filtration.
DIMENSIONS
Nominal O.D. : 2.75" (70mm)
Nominal I.D. : 1.25" (31mm)
Nominal Micron Ratings : 0.2, 0.45, 1 and 3 micron
MATERIALS OF CONSTRUCTION
Filtration Media : Polypropylene Microfiber
Support Layers : Polypropylene Microfiber
Core and Cage : Polypropylene
Endcaps : Polypropylene
OPERATIONAL LIMITS
Efficiency : 98% or above
Maximum Forward Differential Pressure : 60 psi (3.4 bar)
Maximum Reverse Differential Pressure : 20 psi (1.4 bar)
Maximum Operating Temperature : 180oF (82oC) at 10 psid (0.69 bar) in water
Brand : HydroCompos
Model : PF-10-20-EHE
Nominal Micron Rating : 10 micron
End Cap 1 : 222 O-ring
End Cap 2 : Fin
Cap Material : EPDM
Cartridge Length : 20 inch
