Cartridge Filter 5 micron 10 inch

Kami adalah importir distributor agen dan supplier terlengkap untuk menyediakan berbagai kebutuhan spare part filter untuk keperluan industri dengan price harga terbaik

Cartridge filtration units generally operate most effectively and economically on applications having contamination levels of less than 100 ppm. For heavier contamination applications, cartridges are normally used as final polishing filters

Filtration Range 5 micron

Filter Length Size 10” , 20” , 30” , 40”

Diameter filters 2.5” and 4.5”

Applications Cartridge Filter 5 micron 10 inch :

Pre RO water

Chemicals

Beverages

Solvents

Compressed air

Cosmetics

Alcohol

Sediment Filter Cartridge

Spun Bonded Filter Cartridges are made of 100% polypropylene fibers. These fibers have been carefully spun together to form a true gradient density from outer to inner surface. Spun Bonded Filter Cartridges are available with core and without core version. The superior structure remains integral even under severe operating conditions and is no media migration. Polypropylene fibers are blown continuous on central molded core, without the need for binders, resins or lubricants. Operation unfiltered fluid passes through depth filter matrix, enables the progressive retention of finer particles, providing high efficiency, high dirt retention, and filter life. Fluid flows from outside to inside through filter media. Particulates are held securely in the filter matrix and clean fluid flows to the downstream side of cartridge.

Features

·         100 % Polypropylene for wide chemical compatibility

·         Excellent flow with low pressure drop

·         Excellent flow with low pressure drop

·         High strength & pressure resistance

·         Nominal & absolute filtration rating

·         Free of surfactants, Binders and Adhesives

·         High dirt holding capacity

·         One piece construction up to1016 mm. and more

Cartridge Filter 5 micron 10 inch

Technical Specifications

·         Sizes : 10” , 20” , 30” 40” Long

·         Inner Diameter : 25mm , 28 mm , 48 mm

·         Outer Diameter : 64 mm ( 2.5” ) , 114mm ( 4.5” ) , 6” , 8”

·         Micron Rating : 0.5 , 1 , 5, 10, 25, 50 , 75 , 100, 125, 150, 175, 200 micron

Configuration

·         Double Open Type ( DOE Type)

·         Single Open Ended ( SOE Type ) 226 O Ring , 222 O Ring , Flat and Fin

Construction

·         Spun bonded filter cartridges are made up of 100% Polypropylene

Cartridge Filter 5 micron 10 inch

Applications

·         Pharmaceuticals: base product clarifications, membrane pre filter

·         Fine chemicals: solvents, process streams, water purification

·         Food & beverages: bottled water, flavors, polishing lines

·         Petrochemicals: water flood, completion fluids, amines

·         Water treatment: membrane protection, resin trap

·         Cosmetics: alcohols, essential oils , water lines

·         Electronics: electroplating, etching, image development

·         Metal finishing: plating solution, paint and resin products, wash

·         Magnetic coating: dispersions, coating lines, solvents

Untuk permintaan penawaran silahkan hubungi

PT PROFILTER INDONESIA

Ruko Blok G/54 – Gudang A/01

Jl.Canadian Broadway

Kawasan Pergudangan Commpark – Kotawisata – Cibubur

Mobile : 081385066789

Email : sales@profilterindonesia.com
